Product details
Climbing? Running? Geocaching? Or just the good feeling of not having to carry anything and still having everything with you? Our Piko 3 is smaller than a matchbox and weighs only 210 g, including the battery. A CNC-machined aluminium body, active heat management, various light modes and light programs, and a measurable light output of 900 lumens make the Piko a lightweight with endless application possibilities.
Piko X3
Lumen: 900
Light duration: 2h - 46h
Weight: 210g
SmartCore battery: 2.7 Ah
Housing made of polyamide, pad made of polyurethane
Battery: 7.2V 2.7Ah
Watt hours: 18Wh
Dimensions (LxWxH): 79 x 41 x 26mm
Weight: 125g
Protection class: IP 68 (waterproof), IK 09 (impact resistance)
High-current capability: 1C
Cell type: Sanyo UR18650F
PCB: Reversible cut-off in case of short circuit, overvoltage, undervoltage
Suitable for: Piko
Lamp head: Piko 13W
Lumen: 900
Light source: 2-fold Cree XM-L U2
Material: CNC-milled, aluminium 6061-T6, shot-peened, hard-anodised
Dimensions (ØxL): 32 x 24mm
Weight: 55g
Protection class: IP 68 (waterproof)
Microprocessor: 14-bit RISC (4-fold PLL)
Lens: 22° optics (Collimated Lens Technology)
Colour temperature: 6000K (5% tolerance)
Clock speed converter: 50KHz
Processor clock: 32MHz
Conductor structure: Smaller than 0.3 mm
LED board: aluminium
Environmental temperature: -30°C to +55°C
Temperature management: active
Connection cable: highly flexible at -40 to +80°C
LED display: one red and one blue LED
Lighting levels: 5 levels from 0.4W (50 lumens) to 13W (900 lumens)
Voltage display: via red and blue LED
Battery warning lamp head: via red and blue LED
Discharged capacity: via red and blue LED
Reserve tank: depending on battery and usage pattern
Candlelight function: 0.4W
Special levels: SOS, Alpine emergency signal, RVL
Charger: Wiesel V4
Charge current: 0.1 - 1.2A
Input voltage: 100 - 240V~
Frequency: 50 - 60Hz
Display charge control: by 1 LED
Suitable batteries: Li-Ion 7.2V
Functions: charging program
Microprocessor controlled: yes.
