Panasonic 18650 battery and 3-way protection circuit
1 pcs., 3500 mAh, Rechargeable batteryDelivered between Mon, 5.5. and Fri, 9.5.
More than 10 items in stock at third-party supplier
More than 10 items in stock at third-party supplier
Supplied by
Free shipping from 50.–
Product details
The high-quality Panasonic 18650 Li-ion battery with 3500mAh features a triple protection circuit against overcharging, deep discharge, and short circuit. These 3400mAh Li-ion batteries are made from premium Panasonic 18650 Li-ion cells and come with a built-in, high-quality protection circuit to handle high currents. The maximum charging current is 3A, and the maximum discharge current is approximately 11A. Please be cautious if other Li-ion 18650 batteries claim capacities of 4000mAh, 5000mAh, or even 6000mAh. Paper is patient. Our 18650 batteries are sourced as new Panasonic branded cells and equipped with high-quality protection circuits. They are very well suited as a power source for high-quality Fenix LED flashlights such as TK11, TK12, TK15, TK21, TK30, TK35, PD31, PD32, TA20 (only current model), TA21, and TK75. Please note that the battery is not compatible with Nitecore LED lamps.
Technical specifications:
- System: Li-ion battery with triple protection circuit
- Form factor: 18650
- Capacity: 3500mAh
- Nominal voltage: 3.7 Volt
- Standard charging current: 1700mAh
- Standard discharge current: 680mAh
- Standard discharge cut-off voltage: 3.5 Volt
- Diameter: 18.40mm
- Length: 68.66mm +/- 0.2mm
- Maximum continuous current draw: 10A
- Integrated electronics for protection against deep discharge, short circuit, and excessive current draw
Voltage-state of charge for Lithium batteries:
- 4.2V - 100%
- 4.1V - 87%
- 4.0V - 75%
- 3.9V - 55%
- 3.8V - 30%
- 3.5V - 0%
General safety instructions: Please do not leave the batteries unattended while charging, always use batteries from the same manufacturer and of the same type together. When using multiple batteries, they should always be used and charged together. Use a high-quality charger and, if possible, remove the cells after the charging process. Important: Keep the battery voltage above.
Items per sales unit | 1 pcs. |
Accumulator type | Rechargeable battery |
Item number | 12496634 |
Manufacturer | Panasonic |
Category | Battery charger |
Release date | 8.1.2020 |
Accumulator type | Rechargeable battery |
Battery type | Li-ion |
Voltage | 3.70 V |
Capacity | 3500 mAh |
Items per sales unit | 1 pcs. |
Number of charging bays | 3 x |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer Panasonic fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Address | Digitec Galaxus AG, Pfingstweidstrasse 60b, CH‑8005 Zurich |
Ingredients | The high-quality Panasonic 18650 Li-Ion battery with 3500mAhwith triple protection circuit against overcharging, deep discharge, short circuitThese 3400mAh Li-Ion batteries are made from high-quality Panasonic 18650 Li-Ion batteries and have an integrated, high-quality protection circuit with triple protection in order to be able to deliver high currents. The maximum charging current is 3 A and the maximum discharging current is approx. 11 A. Please be sceptical if you are promised capacities of 4,000 mAh, 5,000 mAh or even 6,000 mAh with other Li-Ion 18650 batteries. Paper is patient. Our 18650 batteries are purchased as new Panasonic branded cells and fitted with high-quality protective circuits. Very suitable e.g. as a power source for the high-quality LED torches from Fenix TK11, TK12, TK15, TK21, TK30, TK35, PD31, PD32, TA20 (current model only), TA21 and TK75 etc. Please note, the battery is not compatible with Nitecore LED lamps! Technical data (PCB protection trip current 10A)System: Li-Ion battery with triple protection circuit, 18650 design, capacity 3500mAh, nominal voltage 3.7 Volt, standard charge current 1700mAh, standard discharge current 680mAh, standard final discharge voltage 3.5 Volt, diameter 18.40mm, length 68.66mm +/- 0.2mm, Maximum continuous current drain 10A, Reference size 168A / 600P, Integrated electronics to protect against deep discharge, short circuit and excessive current drain, Voltage state of charge of the lithium batteries: 4.2V - 100% / 4.1V - 87% / 4.0V - 75% / 3.9V - 55% / 3.8V - 30% / 3.5V - 0%General safety instructions: Please do not leave the batteries unattended when charging, always use batteries from the same manufacturer and of the same design together. When using several batteries, always use and charge them together. Use a high-quality charger and remove the cells after charging if possible. Important: keep the battery voltage above 3.8 volts to increase the service life. The cells can be permanently damaged if stored at less than 3.6 volts; always avoid deep discharging below 3.6 volts. |
