Bluechip SERVERline R11201s
Intel Atom C3558, 8 GB, Rack ServerDelivered between Fri, 2.5. and Tue, 6.5.
More than 10 items in stock at third-party supplier
More than 10 items in stock at third-party supplier
Supplied by
JACOB DE
free shipping
Product details
Compact appliances for small businesses. The R11201s, based on the Intel Atom C3000 processor architecture, is perfectly suited for dedicated appliances or virtualized web servers due to its high performance per watt. The advantages of the new Intel Atom processor family include lower power consumption and a performance increase of 2.5 times compared to the previous generation. The system offers up to 16 processor cores, 256 GB of ECC (Error Correcting Code) memory, and four Gigabit RJ45 ports.
Number of rack units | 1 U |
Processor family | Atom |
Processor type | Intel Atom C3558 |
Max. number of hard disks | 2 |
Number of processors | 1 x |
RAM | 8 GB |
Operating system | No operating system |
Item number | 15659447 |
Manufacturer | Bluechip |
Category | Servers |
Manufacturer no. | 850249 |
Release date | 14.4.2021 |
External links |
Design | Rack Server |
Number of rack units | 1 U |
Processor family | Atom |
Processor type | Intel Atom C3558 |
Number of processors | 1 x |
Clock frequency | 2.20 GHz |
Number of threads | 4 |
Number of processor cores | 4 -Core |
Max. turbo clock rate | 2.20 GHz |
Max. TDP | 16 W |
L3 Cache | 8 MB |
Socket | BGA 1310 |
Memory type | DDR4-RAM |
Max. memory slots | 4 |
Memory configuration | 1 x 8GB |
RAM | 8 GB |
Max. RAM | 256 GB |
RAM speed | 2133 MHz |
RAM error correction | ECC |
RAM buffer | Error Correcting Code |
RAID configuration | 0 |
Mass storage controller type | SATA III |
Max. number of hard disks | 2 |
Storage capacity | 480 GB |
Form factor | 2.5" |
Interface | SATA III |
Expansion slot | PCI Express x4 (Gen 3) (1x) |
PCI express version (max.) | 3 |
Internal connection options | S-ATA (1x) |
USB ports | USB-B |
Exact USB ports | USB-B 2.0 (2x) |
Data ports | PS/2 (2x) |
Connectivity | Ethernet |
Network connections | RJ45 (4x) |
Graphics card model | AST2400 |
Video memory type | GDDR4 |
Graphics chip (GPU) | AMD FirePro |
Hardware interface | VGA |
Video connections | VGA (1x) |
Optical drive type | No drive |
Operating system | No operating system |
Processor design | 64-bit |
Power | 200 W |
CO₂-Emission | |
Climate contribution |
Length | 249 mm |
Width | 437 mm |
Height | 43 mm |
Specifications may include unverified machine translations.
